The multimission BELL 505 is ready for anything from adventure excursions to cosseted corporate travel. The 505’s turboshaft engine’s dual-channel FADEC (Full Authority Digital Engine Control) offers enhanced safety and is rated for a maximum cruise speed of 144 mph. Outstanding visibility filled the 505’s 99 cubic-foot cabin with panoramic views of the Berkshires during this year’s Gear Guide photo shoot. While its so called Short Light Single configuration puts the 505 in the company of more lightly equipped aircraft, Bell’s proven track record and state-of-the art avionics ensure the thrill of private air travel is accompanied by peace of mind.


Performance

  • Hover Ceiling IGE
    14,450 ft / 4,404 m
  • Hover Ceiling OGE
    10,460 ft / 3,188 m
  • Max Cruise
    125 kts | 231 km/h
  • Service Ceiling (Pressure Altitude)
    18,610 ft PA / 5,672 m PA
  • Range at VLRC*
    306 nm | 566 km
  • Max Endurance (No reserves, 60 KIAS)
    > 3.9+ hrs

Capacity

  • Baggage Compartment Volume
    18 ft3 / 0.5 m3
  • Cabin Floor Area**
    22 ft2 / 2.0 m2
  • Empty Weight – (base aircraft)
    2,180 lbs / 989 kg
  • External Useful Load
    2,295 lbs / 1,041 kg
  • Internal Useful Load
    1,500 lbs / 680 kg
  • Max Gross Weight (external)
    4,475 lbs / 2,030 kg
  • Max Gross Weight (internal)
    3,680 lbs / 1,669 kg

Price

  • PRICE UPON REQUEST
